Vertical Pressure Steam Sterilizer TRE735A/750A/775A/700A

ELECTRIC-HEATED VERTICAL STEAM STERILIZE TRE735A/750A/775A/700A
   (hand  round automatic)

Characteristics:
1.Fully stainless steel structure
2.Hand wheel type of quick-open door structure
3.Pressure safety lock
4.Indicator light indicates working state
5.Over temperature & over pressure auto-protection
6.Double scale indication pressure gauge
7.Self inflating type seal
8.Safe protection of water lacking
9.Automatically shut off with beep reminding after sterilization
10.Easy to operate,safe and reliable
11.With two stainless steel sterilizing baskets

Valid volume:35L(φ318*450mm)

50L(φ340*550mm)     75L(φ400*600mm)

100l(φ440*650)

Working pressure:0.22Mpa  0.22mpa  0.22mpa  0.14mpa

Working temperature:134℃ 134℃ 134℃ 126℃

Max. working pressure:0.23Mpa0.23Mpa0.23Mpa0.165Mpa

Heat average: ≤±1℃

Timer: 0-60min

Adjustment of temperature:105-134℃ 105-134℃105-134℃105-126℃

Power:2.5kw/AC220V.50Hz    3kw/AC220V.50Hz   4.5kw/AC220V.50Hz   4.5kw/AC220.50hz

Transport dimension:570*550*1150(mm)     590*590*1280(mm)  650*630*1280(mm) 680*630*1370(mm)

G/N.W:72kg/56kg 88kg/68kg   100kg/80kg   110kg/85kg
